3C product pulp package machine ZAP9585

The ZAP9585 High-end Industrial Package Machine is the cost-effective star in the packaging machinery industry. This machine is known for its low investment and high output, ensuring you do more with less. ZAP9585 solves the needs of various industries such as 3c electronics, big consumption, big health, medical industry consumables, biotechnology, cosmetics, daily chemicals and other related packaging materials.

With the ZAP9585, you can finish hot pressing and forming efficiently on one machine without compromising your product quality. This feature can significantly reduce production time and increase output.

Flexible and adaptable, the ZAP9585 can easily handle a wide range of products, especially those with demanding quality requirements. Whether you need to pack small items or large items, you can customize a machine to meet your specific needs. So you can maintain high quality standards and increase customer satisfaction.

Furthermore, the ZAP9585 is designed to meet high operating requirements while maintaining low power consumption. With its advanced technology, you can easily control temperature, pressure and molding speed to produce the best results without wasting energy. The machines low energy consumption means reduced utility bills and carbon footprint, making it an environmentally friendly choice.

Advantages of Products

Higher output , less consumption, high-end solution, perfect product quality

产能上升更新后的
3 0 %+
Capacity per sqm Up by
热能耗下降更新后的
1 0 %
Heating Consumption Less by
清洗周期更新后的
1500 0 +
Mold Deep Cleaning Cycle
90直径产能更新后的
2 0 %
Less energy consumption
Commonly Used Raw Material
Primary Pulp Board from the following plants
The commercial primary pulp board for producing disposable tableware is usually chemical pulp or chlorine-free ECF pulp ,can be purchased from paper making manufacture. One-year plant fiber is the proven more proper raw material for pulp molded tableware production for the fiber length is shorter,like sugarcane bagasse fiber,bamboo fiber,wheat straw fiber,reed straw fiber or some offcut of office paper.Wood fiber or bamboo fiber would be added by certain ratio for producing some products of complex structure or deeper products.

Application

Mainly used to Produce Phone tray, tablet tray,earphone tray,watch tray, mouse tray

MACHINE SPECIFICATIONS

ZAP9585 3C product pulp package machine

1

Outer dimension (L*W*H)

4100mm*1680mm*3300mm

2

Platen size

850mm*850mm

3

Forming method

reciprocating

4

Pulp feeding style

accurate quantitative pulp feeding (external overflow style)

5

Heating method

electric/thermal oil heating

6

Product transfer method

product transfer method

7

Forming pressure

10T

8

Hot pressing pressure

40T

9

Machine drive mode

servo + lead screw & hydraulic system

10

Control system

PLC+ touch screen

11

Drying method

dry in-mold

12

Capacity

200-500KG/22H

13

Cycle time

38-120 seconds/drop (depends on the product)

14

Max. product height

100mm

Production Flowchart

ONE-STOP SOLUTION ,TURNKEY PROJECT
播放视频

High-End Industrial Package Machine

Solution for complex structure, 0 angle demolding, make sure finish product with perfect smoothness and strength
